Overview
The Procon 113A100F11XX is a positive-displacement rotary vane water pump manufactured by Procon (CEME Group). Its stainless steel housing is built to deliver 100 GPH (379 LPH) at user-selected pressure with consistent flow across the entire pressure range. Procon rotary vane pumps are self-priming (water), maintenance-free, and virtually silent, making them a standard component in reverse-osmosis, carbonation, beverage-dispensing, coffee, and cooling systems worldwide. NSF-61 lead-free compliant.
Typical Applications
Reverse Osmosis, Carbonation, Beverage Dispensing, Cooling Systems, Solar, General
Key Features & Benefits
- Positive-displacement design delivers consistent flow at variable pressures
- Self-priming with water; maintenance-free apart from optional strainer cleaning
- Low starting torque — compatible with standard carbonator motors
- Quiet operation with low vibration and pulsation (≤ 60 dBA)
- Stainless Steel housing rated for clean fluid service up to 160�F and 100cP viscosity
- Built to Procon ISO-9001 quality system in Mexico and Ireland
- NSF/ANSI 61 lead-free compliant — approved for potable drinking-water systems
Installation Notes
- Provide clean, filtered fluid on the suction side. Use a strainer if the source may contain debris.
- Do not run the pump dry for more than 2 minutes.
- Do not operate against a closed discharge without a relief valve.
- Pump inlet / outlet is 3/8-inch NPT thread.
About Procon
Established in 1948, Procon engineers dependable positive-displacement vane and gear pumps. Part of the CEME Group, Procon operates ISO-9001 certified plants and serves OEMs in 70+ countries. Procon rotary vane pumps are the industry standard in commercial carbonation, espresso, and reverse-osmosis systems.
