Danfoss Positive Displacement Pumps
| Technical Data | |
|---|---|
| Part Number | PAHT G 308 |
| Type | PAHT G 256-308 |
| Description | Pump for ultra pure water |
| Body Material | AISI 316 |
| Seal Material | NBR |
| Displacement | 308 cm³/rev |
| Max Flow | 72 gal/min |
| Min Flow | 28 gal/min |
| Max Outlet Pressure | 1740 psig |
| Min Outlet Pressure | 435 psig |
| Max Inlet Pressure | 87 psig |
| Min Inlet Pressure | 29 psig |
| Max Speed | 1250 rpm |
| Min Speed | 450 rpm |
| Inlet Standard | Metric |
| Outlet Standard | Metric |
| Max Media Temp | 122 °F |
| Min Media Temp | 36 °F |
| Max Ambient Temp | 122 °F |
| Sound Level | 87 dBA |
| Net Weight | 95.876 Kilogram |
| Gross Weight | 121.667 Kilogram |
| Dimensions (L x W x H) | 22x13,2x18,3 |
| Approval | CE |
| ATEX | No |
| CE Mark | Yes |
| Country of Origin | Denmark |
| EAN | 5715162670446 |
| Serviceable | Spare parts PAHT G 256/308 |
| Warranty | Danfoss guarantees 8,000 hours of service-free operation (max. 18 months from date of production) when installed and operated to Danfoss specifications — see the product manual for conditions |
📄 Download the Danfoss Data Sheet (PDF) Official Danfoss document AI106586503089en
📄 Download the Danfoss Operation Manual (PDF) Official Danfoss document AQ188686502990en
