The Grundfos CM 1-9 is a horizontal multistage centrifugal pump (Grundfos part number 99155418). It is rated at 1.5 HP, three-phase 208-230/440-480V, 60 Hz, and features all AISI 316 stainless steel construction for aggressive or high-purity media with an AQQV shaft seal (carbon / silicon-carbide faces, FKM/Viton elastomers for oils and aggressive media).
Specifications
| Model | CM 1-9 |
|---|---|
| Grundfos part number | 99155418 |
| Pump type | Horizontal multistage centrifugal pump |
| Power | 1.5 HP |
| Electrical | Three-phase, 208-230/440-480V, 60 Hz |
| Construction | all AISI 316 stainless steel construction for aggressive or high-purity media |
| Shaft seal | AQQV shaft seal (carbon / silicon-carbide faces, FKM/Viton elastomers for oils and aggressive media) |
| Shipping weight | 43.0 lb |
| Shipping dimensions (W×H×L) | 10 × 12 × 27 in |
Applications
The Grundfos CM 1-9 is used for municipal and private water supply, pressure boosting, water treatment and filtration, washing and cleaning systems, cooling and air-conditioning, and general industrial liquid transfer.
About this pump
Grundfos CM/CME horizontal multistage pumps deliver high efficiency in a compact, in-line footprint. The CM 1-9 ships as a complete unit with motor. For help selecting the correct model, number of stages, or materials for your application, contact ForeverPure Place for a quote.
