The Grundfos CM 3-4 is a horizontal multistage centrifugal pump (Grundfos part number 97568360). It is rated at 1 HP, three-phase 208-230/440-480V, 60 Hz, and features cast-iron pump head and base with AISI 304 stainless steel hydraulic components with an AQQE shaft seal (carbon / silicon-carbide faces, EPDM elastomers).
Specifications
| Model | CM 3-4 |
|---|---|
| Grundfos part number | 97568360 |
| Pump type | Horizontal multistage centrifugal pump |
| Power | 1 HP |
| Electrical | Three-phase, 208-230/440-480V, 60 Hz |
| Construction | cast-iron pump head and base with AISI 304 stainless steel hydraulic components |
| Shaft seal | AQQE shaft seal (carbon / silicon-carbide faces, EPDM elastomers) |
| Shipping weight | 33.0 lb |
| Shipping dimensions (W×H×L) | 10 × 12 × 20 in |
Applications
The Grundfos CM 3-4 is used for municipal and private water supply, pressure boosting, water treatment and filtration, washing and cleaning systems, cooling and air-conditioning, and general industrial liquid transfer.
About this pump
Grundfos CM/CME horizontal multistage pumps deliver high efficiency in a compact, in-line footprint. The CM 3-4 ships as a complete unit with motor. For help selecting the correct model, number of stages, or materials for your application, contact ForeverPure Place for a quote.
