The Grundfos CME 10-2 is a horizontal multistage centrifugal e-pump (integrated variable-speed MGE motor) (Grundfos part number 99329881). It is rated at 3 HP, three-phase 440-480V, 60 Hz, and features cast-iron pump head and base with AISI 304 stainless steel hydraulic components with an AQQE shaft seal (carbon / silicon-carbide faces, EPDM elastomers).
Specifications
| Model | CME 10-2 |
|---|---|
| Grundfos part number | 99329881 |
| Pump type | Horizontal multistage centrifugal e-pump (integrated variable-speed mge motor) |
| Power | 3 HP |
| Electrical | Three-phase, 440-480V, 60 Hz |
| Construction | cast-iron pump head and base with AISI 304 stainless steel hydraulic components |
| Shaft seal | AQQE shaft seal (carbon / silicon-carbide faces, EPDM elastomers) |
| Shipping weight | 100.0 lb |
| Shipping dimensions (W×H×L) | 15 × 15 × 25 in |
Applications
The Grundfos CME 10-2 is used for constant-pressure water supply and boosting, water treatment, washing systems, and energy-efficient industrial transfer with built-in speed control.
About this pump
Grundfos CM/CME horizontal multistage pumps deliver high efficiency in a compact, in-line footprint. The CME 10-2 ships as a complete unit with motor. For help selecting the correct model, number of stages, or materials for your application, contact ForeverPure Place for a quote.
