The Grundfos CRI 3-23 is a vertical multistage centrifugal pump (AISI 304 stainless steel) (Grundfos part number 99916504). It is rated at 5 HP, three-phase 208-230/460V, 60 Hz, and features all AISI 304 stainless steel construction with an HQQV shaft seal (tungsten-carbide / silicon-carbide faces, FKM/Viton elastomers).
Specifications
| Model | CRI 3-23 |
|---|---|
| Grundfos part number | 99916504 |
| Pump type | Vertical multistage centrifugal pump (aisi 304 stainless steel) |
| Power | 5 HP |
| Electrical | Three-phase, 208-230/460V, 60 Hz |
| Construction | all AISI 304 stainless steel construction |
| Shaft seal | HQQV shaft seal (tungsten-carbide / silicon-carbide faces, FKM/Viton elastomers) |
| Shipping weight | 123 lb |
| Shipping dimensions (W×H×L) | 14 × 14 × 53 in |
Applications
The Grundfos CRI 3-23 is used for water treatment, light-corrosive and demineralized water, filtration, food and beverage, and industrial process where AISI 304 wetted parts are required.
About this pump
Grundfos CR-range vertical multistage pumps are an industry standard for reliable, efficient high-pressure pumping. The CRI 3-23 ships as a complete unit with motor. For help selecting the correct model, number of stages, or materials for your application, contact ForeverPure Place for a quote.
