Overview
The HomeGrid Stack'd Series builds a battery bank the way you build with blocks: 4.8 kWh LFP modules stack two to eight high on a single base, from 9.6 kWh to 38.4 kWh per tower — no wall mounting, no rack, minimal wiring. Towers parallel for even larger systems, and closed-loop profiles cover Sol-Ark, Victron, Schneider and more.
Key Features
- Modular: 4.8 kWh LFP modules, stack 2–8 per tower (9.6–38.4 kWh)
- 48V architecture compatible with major hybrid/off-grid inverters
- Floor-standing tower — no wall load, fast tool-light install
- Parallel multiple towers for commercial-scale banks
- Closed-loop communications: Sol-Ark, Victron, Schneider and more
- 10-year warranty; UL-recognized LFP cells
Technical Specifications
| Module Capacity | 4.8 kWh (LFP) |
| Tower Range | 9.6 – 38.4 kWh (2–8 modules) |
| Voltage | 51.2 V nominal |
| Expansion | Stack modules or parallel towers |
| Communication | CAN/RS485 closed-loop |
| Installation | Indoor/protected, floor standing |
| Module Weight | ~99 lb each; tower shipped palletized |
| Warranty | 10 years |
Specifications verified against the manufacturer's official documentation: HomeGrid official Stack'd Series documentation.
Applications
Grow storage with your water system: start with a 3-module tower for overnight RO operation and add modules as production scales — without touching the wiring.
Frequently Asked Questions
Which configuration should I order?
Towers ship as 2–8 module kits (HG-4 = 19.2 kWh and HG-8 = 38.4 kWh are most popular). Tell us your loads and inverter and we'll spec the tower.
Can I add modules later?
Yes — additional modules stack onto the existing base and register with the BMS; capacity grows in 4.8 kWh steps.
Which inverters are supported?
Closed-loop profiles for Sol-Ark, Victron, Schneider, Growatt, Deye and others; open-loop voltage control works with the rest.
What is the lead time?
Lead times vary with manufacturer production and freight schedules. Contact us at 408-969-2688 or sales@foreverpureplace.com and we will confirm current lead time and reserve stock for your project.
Why is no price shown?
Battery pricing changes frequently with manufacturer programs and freight. We quote current pricing the same day — call 408-969-2688 or use the Contact Us link and we'll respond with a formal quote.
Documents & Downloads
All documents open from the manufacturer's official resources.
