📄 Download the Danfoss Data Sheet (PDF) Official Danfoss document AI264763692435en
Danfoss Electric Motors
| Technical Data | |
|---|---|
| Part Number | ISAVE 70 |
| Type | iSave 50-70 |
| Description | iSave 70 (Without motor) |
| Seal Material | NBR |
| Min Flow | 220 gal/min |
| Max Speed | 875 rpm |
| Min Speed | 650 rpm |
| Max Media Temp | 95 °F |
| Min Media Temp | 36 °F |
| Max Ambient Temp | 122 °F |
| Sound Level | 86 dBA |
| Net Weight | 163.5 Kilogram |
| Gross Weight | 187 Kilogram |
| Dimensions (L x W x H) | 34,6x16,7x19,5 |
| Approval | CE |
| CE Mark | Yes |
| Country of Origin | Denmark |
| EAN | 5715162673188 |
| Serviceable | Yes |
| Warranty | Danfoss guarantees 8,000 hours of service-free operation (max. 18 months from date of production) when installed and operated to Danfoss specifications — see the product manual for conditions |
📄 Download the Danfoss Operation Manual (PDF) Official Danfoss document AQ265943679828en
Question? Please contact us for pricing, lead times, and technical support.
